DAHUA 4 CHANNEL XVR1B04-I - 2MP SUPPORTED PENTA-BRID 1080N/720P DIGITAL VIDEO RECORDER - KUN TRADERS

PRODUCT SPECIFICATION:

• Processor: Industrial-grade processor
• Operating System: Embedded Linux
• Operating Interface: Web, Local GUI, AI by Recorder SMD Plus, AI by DVR SMD Plus
• Analog Camera Input: 4 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect
• IP Camera Input: Up to 5 channels of IPC access, 1 IP channel by default + 4 channels (analog channels converted to IP channels)
• Main stream: 1080N/720p/960H/D1/CIF@(1 fps–25/30 fps)
• Sub stream: CIF@(1 fps–15 fps)
• Dual-stream: Yes

• PAL: 1 fps–25 fps
• NTSC: 1 fps–30 fps
• Video Bit Rate: 32 kbps–4096 kbps
• Audio Sampling: 8 kHz, 16 bit
• Audio Bit Rate: 64 kbps
• Video Output: 1 HDMI, 1 VGA
• Multi-screen Display:1/4 (when IP extension mode not enabled),1/4/6 (when IP extension mode enabled)
• Third-party Camera Access: Panasonic, Sony, Hanwha, Axis, Arecont, ONVIF
• Video Compression: AI Coding, Smart H.265+, H.265, Smart H.264+, H.264
• Audio Compression: G.711a, G.711u, PCM
• Network Protocol: HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, P2P, Auto Registration, IP Search
• Mobile Phone Access: iOS, Android
• Interoperability: ONVIF 22.12 (Profile T, Profile S, Profile G), CGI, SDK
• Browser: Chrome, IE, Safari, Edge, Firefox
• Network Mode: Single-address mode
• Record Mode: General, alarm, motion detection, intelligent
• Recording Playback: 1/4
• Backup Method: USB device and network
• Playback Mode: Instant playback, general playback, event playback, tag playback, smart playback
• General Alarm: Motion detection, HDCVI alarm, camera external alarm, network alarm, PIR alarm
• Anomaly Alarm: Error (no disk, disk error, low space, low quota space, network disconnection, IP conflict, MAC conflict), video loss, video tampering, camera offline
• Intelligent Alarm: SMD Plus Alarm Linkage
• Audio Input: 1-channel RCA, 4-channel BNC (Coaxial Audio)
• Audio Output: 1-channel RCA
• Two-way Talk: Yes (shares the same audio input with the first channel)
• Disk Interface: 1 SATA port, up to 6 TB (depending on environment temperature)
• USB: 2 (2 rear USB 2.0 ports)
• HDMI: 1
• VGA: 1
• Network Port: 1 (10/100 Mbps Ethernet port, RJ-45)
• Power Supply: 12 VDC, 1.5 A
