8-port Managed PoE Switch
Layer 2 Gigabit PoE Switch
SPECIFICATIONS:
System Overview
The DH-PFS4210-8GT-150 is an 8-port, Gigabit, managed PoE Ethernet
switch, which supports the IEEE802.3 af/at standards. The switch also
supports Layer 2 network management and PoE management and
provides high-speed data forwarding.
| Technical SpecificaƟon | |
| Ethernet Ports | Eight (8) 10/100/1000 Base-T Ports (PoE Power Supply) Two (2) 1000 Base-X Ports |
| PoE Power Consumption | Each port: ≤ 30 W, Total: ≤ 150 W |
| PoE Protocol | PoE (IEEE802.3af), PoE+ (IEEE802.3at) |
| Switching Capacity | 36 Gbps |
| Packet Forwarding Rate | 14.88 Mpps |
| Packet Buffer Memory | 4.1 MB |
| Power Requirements | 100 VAC to 240 VAC |
| Working Temperature | -10° C to 55° C (14° F to 131° F) |
| Application Humidity | 10% to 90% |
| Lightning Protection | Common Mode: 2 KV Differential Mode: 500 V |
| Operating Temperature | -10° C to 55° C (14° F to 131° F) |
| Dimensions (W x D x H) | 330.0 mm x 230.0 mm x 44.0 mm (13.0 in. x 9.06 in. x 1.73 in.) |
| Weight | 2.35 kg (5.18 lb) |
| Service Specification | |
| System | Username/Password: admin/admin |
| IP Address: 192.168.1.110/24 | |
| PoE Budget | 150 W |
| MAC Table Size | 8K |
| VLAN | 802.1Q |
| Port Aggregation | Manual |
| Port Mirroring | Many-to-One Port Mirroring |
| Flow Control | Half-duplex based on back pressure type control |
| Full Duplex based on PAUSE Frame | |
| Multicast | IGMP Snooping |
| Quality of Service | Diff-Serv QoS |
| Four (4) Output Queue, each port | |
| 802.1p/DSCP Priority Mapping | |
| Security Features | Hardware Supports IP+MAC Binding based on port |
| IP Source Address Protection | |
| ARP Detection | |
| System Maintenance | Configuration file upload/download |
| Updated packet upload | |
| System logs | |
| Network Management | Web (HTTP protocol) |
Ordering Information
| Type | Part Number | Description |
| PoE Switch | DH-PFS4210-8GT-150 PFT3950 |
Layer 2, 8-port Managed PoE Switch |
| Accessories | 1.25 G, 850 nm, 500 m, LC, Multi-mode | |
| PFT3960 | 1.25 G, 1310/1550 nm, 20 km, LC, Single-mode | |
| PFT3970 1.25 G, 1550/1310 nm, 20 km, LC, Single-mode |
