DH-IPC-HFW2431SP-SS2 | Dahua 4MP Bullet Camera | KUN TRADERS

FEATURES:

Camera Specifications:

1. Image Sensor: 1/3" CMOS
2. Pixel: 4 MP
3. Max Resolution: 2688 (H) × 1520 (V)
4. ROM: 128 MB
5. RAM: 128 MB
6. Scanning System: Progressive
7. Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
8. Min. Illumination: 0.008 Lux@F1.6
9. S/N Ratio: ＞56 dB
10. Illumination Distance: 30 m(IR)
11. Illuminator On/Off Control: Auto/Manual
12. Illuminator Number: 1 (IR LED)
13. Pan/Tilt/Rotation Range: Horizonal: 0°–360°, Vertical: 0°–90°, Rotation: 0°–360°
14. Built-in Battery: Support SUPERCAP 0.08 F
15. Lens Type: Fixed-focal
16. Lens Mount: M12
17. Focal Length: 2.8 mm; 3.6 mm
18. Max. Aperture: F1.6
19. Field of View: Horizontal: 102.0°; Vertical: 55.0°; Diagonal: 121.0°
20. Iris Control: Fixed
21. Close Focus Distance: 0.9 m; 1.6 m
22. DORI Distance: D:63.6m; O:25.4m; R:12.7m; I:6.4m
23. IVS: Intrusion; tripwire
24. Video Compression: H.265; H.264; H.264B; MJPEG
25. Smart Codec: H.264: Yes; H.265: Yes
26. Video Frame Rate: 50Hz; 60Hz
27. Stream Capability: 2 streams
28. Resolution: 2688 × 1520; 2560 × 1440; ...
29. Bit Rate Control: CBR/VBR
30. Video Bit Rate: H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps

Network and Security

1. Network Port: RJ-45 (10/100 Base-T)
2. SDK and API: Yes
3. Network Protocol: HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; QoS; UPnP; NTP; RTMP; Multicast; HTTPS; SFTP; 802.1x; ICMP; IGMP
4. Interoperability: ONVIF(Profile S/Profile G); CGI; P2P; Milestone; Genetec
5. User/Host: 20
6. Storage: Dahua Cloud; FTP; Micro SD card (max. 256 GB); NAS
7. Browser: IE; Chrome; Firefox
8. Management Software: Smart PSS; DSS; DMSS
9. Mobile Client: iOS; Android
10. Image Setting: Brightness; Contrast; Sharpness; Saturation; Gamma
11. OSD Overlay: Time; channel; location
12. Record Mode: Record manually; video detection record; schedule record
13. Record priority: Manual > video detection > schedule
14. Micro SD Card (Max.): 256 GB
15. Default Support: one-click restore
16. User Management: Up to 20 Security
17. User name and password: MAC address; HTTPS; IEEE802.1x; network access control

Certifications and Power

1. Certifications: CE-LVD; CE-EMC; FCC; UL/CUL; CAN/CSA
2. Operating Voltage: 12V DC(± 30%); POE (802.3af)
3. Power Supply: 12 VDC/PoE (802.3af)
4. Power Consumption: Basic power consumption: 2.2W (12V DC); 2.7W (POE)
5. Max power consumption: (H.265, Max resolution, Max stream, WDR, IR full intensity, IVS): 4.2W (12V DC), 5W (POE)

Environmental and Physical

1. Operating Temperature: -40°C to +60°C (-40°F to +140°F
