IP-COM G1105P-4-63W 5-PORT 1000MBPS GIGABIT PoE SWITCH WITH 1 UPLINK PORT, 63W - KUN TRADERS

IP-COM G1105P-4-63W 5-PORT 1000MBPS GIGABIT PoE SWITCH WITH 1 UPLINK PORT, 63W - KUN TRADERS

Rs.0.00 PKR
Rs.0.00 PKR
Sale Sold out
Shipping calculated at checkout.

FEATURES:

G1105P-4-63W

5-Port Gigabit Desktop Switch with 4-Port PoE

  • 5 10/100/1000 Mbps Base-T RJ45 port
  • Ports 1-4: IEEE 802.3af/at PoE ports
  • maximum power output of each PoE port: 30 W maximum power output of the switch: 58 W
  • Desktop size,Power Adapter Output 63W
  • Support One-Key VLAN, Port 1-4 will be isolated respectively but can communicate with the 5 port

SPECIFICATIONS:



Standard&Protocol IEEE 802.3、IEEE 802.3u、IEEE 802.3ab、IEEE 802.3x、IEEE 802.3af、IEEE 802.3at
MTBF ≥100,000hours
Indicator 5*Link/Act per device
4*PoE per device
1*Power per device
Interface 4 10/100/1000Base-T ports(Data/Power)
1 10/100/1000Base-T port(Data)
Port Lightning Protection 6KV
Store and forward Yes
Exchange Capacity 10 Gbps
Packet forwarding rate 7.44Mpps
RAM Data Buffer 1Mb
MAC Address Table 2K
PoE supply management Port 1 to Port 4 support  IEEE802.3at/af PoE standard
PoE through pin 1 2 4 5 +，3 6 7 8 -
Voltage input range AC：100-240V～ 50/60Hz
Dimensions 100*100*26mm ( W x D x H )
Power Consumption in full configuration：<63W
PoE Max Power Supply：58W
Port Features Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.
VLAN: In this mode,1-4 ports of the switch cannot communicate with each other, but can communicate with the 5 port .Solid DIP switch to isolate ports to prevent broadcast storm and defend DHCP spoofing。
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
