IP-COM 5-PORT GIGABIT PoE++ SWITCH G1105PD - 60W POWER, 1000MBPS, CMPACT DESIGN - KUN TRADERS

IP-COM 5-PORT GIGABIT PoE++ SWITCH G1105PD - 60W POWER, 1000MBPS, CMPACT DESIGN - KUN TRADERS

Rs.0.00 PKR
Rs.0.00 PKR
Sale Sold out
Shipping calculated at checkout.

FEATURES:

G1105PD

5-Port Gigabit PD Switch With 4-Port PoE

  • Five 10/100/1000 Mbps auto-negotiation ports
  • Port 5 supports power supply by a PSE compliant with IEEE 802.3af/at
  • Ports 1 - 4 support power supply to low-power PDs compliant with IEEE 802.3af
  • The switch supports auto MDI/MDIX, simplifing the network structure and maintenance
  • The non-blocking wire-speed forwarding function guarantees the smooth operation of network applications
  • Full-duplex flow control and half-duplex back pressure control prevent frame loss caused by port blocking
  • The switch supports the store-and-forward transfer mode and a 2 K MAC address table
  • The switch supports 9K jumbo frame, improving the forwarding rate of large files
  • The switch supports IP camera connection and guarantees the smoothness and clearness of monitoring videos

SPECIFICATIONS:

Hardware specifications
Network standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at
Transmission media 10Base-T: CAT3 UTP or better
100Base-TX: CAT5 UTP or better
1000Base-T: CAT5e UTP or better
Dimensions 100 mm x 100 mm x 26 mm(L x W x H)
Product material Metal
Fan Fanless
LED indicators 1 x Power LED indicator
4 x PoE LED indicator
5 x Link/Act LED indicator
Service port description
Fixed ports 5 x 10/100/1000 Mbps auto-negotiation RJ45 ports (supporting Auto MDI/MDIX)
PoE out PoE standard:IEEE 802.3af
PoE power cable core:8 cores: voltage of cores 1, 2, 4, 5 is +, and cores 3, 6, 7, 8 is -
PoE port:1 - 4
Maximum output power of a single port:15.4 W
Maximum output power of the switch:22 W
PoE in PoE in standard:IEEE802.3af, IEEE802.3at
PoE in port:5
PoE input:50 - 57V DC, 0.6A
Protection Port lightning protection: 6 kV
Power lightning protection: No
Electrostatic protection:
- Air discharge: ±8 kV
- Contact discharge: ±6 kV
Performance
Forwarding mode Store-and-forward
Switching capacity 10 Gbps
Packet forwarding rate 10 Mbps: 14880 pps
100 Mbps: 148800 pps
1000 Mbps: 1488000 pps
Buffer 1 Mb
MAC address table 2 K
Jumbo frame 9 K
Installation method Desktop mounting: Support
Wall mounting: Not support
Rack mounting: Not support
Environment Operating temperature: 0°C - 45°C
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%), non-condensing
Storage humidity: (5% - 90%), non-condensing
Certificates CQC, FCC, CE, RoHS
Software specifications
Protocol CDMA/CD
MAC address learning Auto-learning, auto-updating
Function No
